Oil-free compressed air at the highest level: the latest generation SO sets the standard for oil-free screw compressors in the 110 to 355 kW performance class. The hallmark of the series: high output volumes at low specific power requirements, quiet operation and a service-friendly design concept.
PRODUCT
Oil-free screw compressor
ADVANTAGES
- heat recovery can be integrated
- Prime control
- oil-free compressed air
- high free air delivery
- maximum efficiency
| BOGE | Pressure | Effective Delivery Volume 50 Hz |
Motor Power | Dimensions W × H × D |
Weight |
|---|---|---|---|---|---|
| Type | barpsig | m3/mincfm | kWPS | mm | kg |
| SO 270-2 W | 8115 | 34.9001,232.0 | 200.0270.0 | 3780 x 1800 x 2150 | 5200 |
| SO 270-2 W | 10150 | 28.4001,003.0 | 200.0270.0 | 3780 x 1800 x 2150 | 5200 |
| SO 340-2 W | 8115 | 42.3601,496.0 | 250.0340.0 | 3780 x 1800 x 2150 | 5400 |
| SO 340-2 W | 10150 | 35.9201,269.0 | 250.0340.0 | 3780 x 1800 x 2150 | 5400 |
| SO 430-2 W | 8115 | 47.2201,668.0 | 315.0430.0 | 3780 x 1800 x 2150 | 5550 |
| SO 430-2 W | 10150 | 46.8901,656.0 | 315.0430.0 | 3780 x 1800 x 2150 | 5550 |
| SO 431-2 W | 8115 | 51.4901,818.0 | 315.0430.0 | 3780 x 1800 x 2150 | 5550 |
| SO 480-2 W | 10150 | 51.4101,816.0 | 355.0480.0 | 3780 x 1800 x 2150 | 5550 |
